0 I found this information on the web, only one place. Here's the wiring info on the Harbor Freight security camera. You can find more information at the link. Yellow is for the microphone Blue is for the camera White is the COMMON GROUND Orange is the power (7.5 VDC @ 300 mA (9 VDC will work)) I'm getting started on repairing my Harbor Freight camera model 91202
